Accesories Holiday Detector

agen distributor accesories holiday detector battery holder rolling spring bronze probe jual murah di jakarta indonesia

Elcometer menawarkan berbagai macam probe dan aksesori detektor tegangan tinggi yang sesuai dengan semua aplikasi dan substrat.

Pegas bergulir dan sikat kawat ‘tipe-C’ ideal untuk memeriksa lapisan pada pipa dan saluran pipa.

Setiap pegas dilengkapi dengan kopling yang mudah dilepas, memungkinkan pengguna untuk dengan cepat menghubungkan dan memutuskan pegas bergulir dari tiang penyangga, pilar, dll.

Pegas bergulir tersedia dalam 2 versi, pegas bulat perunggu fosfor dan pegas berpenampang kotak baja tahan karat 304. Pegas fosfor perunggu berdiameter 19 mm (0,75 ”) hampir 3 kali lebih ringan dari pegas baja tahan karat berdiameter 34 mm (1,33”).

Alas pentanahan ideal untuk pengujian pada pipa yang tidak dibumikan. Alas karet konduktif dililitkan di sekitar pipa berlapis dan dihubungkan ke pin pentanahan (disediakan secara terpisah) dan kabel balik sinyal.

Spesifikasi

BatteriesTelescopic ProbesAccessory AdaptorsBand Brush ProbesWire Brush ProbesConductive Rubber ProbesRolling SpringsGrounding Mats
Part NumberDescription Compatible with Elcometer
   236266280
Batteries, Chargers & Earth Signal Return Leads
Battery ChargerT23615550External rechargeable battery pack

■


T23613907Battery charger & mains lead (UK 240V)

■


T23613908Battery charger & mains lead (EU 220V)

■


T23613909Battery charger & mains lead (US 110V)

■


T99923482Rechargeable lithium ion battery pack

■

■

T99919999

Battery Charger with UK, EUR, US and AUS plugs



■

■


Earth Signal Return LeadT236139031Earth signal return lead, 2m (6.5′)

■


T236139032Earth signal return lead, 10m (32′)

■


T99916954Earth signal return lead, 4m (13′)

■


T99916996Earth signal return lead, 10m (32′)

■


T2802275010m (32′) earth lead, clip / Elcometer 280 connector

■

T28022622Trailing signal return lead, 5m (16′)

■

Telescopic Probes, Probe Extension Rods
Telescopic Probe HandleT23622790-1Telescopic probe handle, 0.6 – 1.20m (24 – 47″)

□


T23622790-2Telescopic probe handle, 1.8 – 3.60m (71 – 142″)

□


T99919988-3Probe extension piece, 250mm (9.8″)

□

■

■

T99919988-1Probe extension piece, 500mm (20″)

□

■

■

T99919988-2Probe extension piece, 1000mm (39″)

□

■

■

Accessory Adaptors, allowing other manufacturer’s accessories to fit Elcometer models
Accessory Adaptor     T99920084Adaptor for models:  AP, APS, AP/S1, AP/S2, AP/W,
10/20, 14/20,10, 20 & 20S

□

■

■

T99920083Adaptor for models:  P20, P40, P60, 780, 785 & 790

□

■

■

T99920252Adaptor for models:  PHD 1-20 & PHD 2-40

□

■

■

T99922747Adaptor for models:   4S, 4.0, 8.0, 35

□

■

■

T99920082Adaptor for current range to fit old accessories

■

■

■

T99922768Adaptor for Elcometer 136 and older 236 models

■


Band Brush Probes
Band Brush Probes  T99919975Band brush probe

□

■

■

T99922751Phosphor bronze brush probe

□

■

■



□ Older Elcometer 236 models may require adaptor piece T99922768

 Part NumberDescription  Compatible with Elcometer
     236266280

Wire Brush Probes, flat brush, internal and external pipe brush probes

   Width
Wire Brush Probe     T99920022-1Right angled wire brush probe0.25m9.8″

□

■

■

T99920022-2Right angled wire brush probe0.50m19.7″

□

■

■

T99920022-3Right angled wire brush probe1.00m39″

□

■

■

T99926621Spare wire brush electrode0.25m9.8″

■

■

■

T99926622Spare wire brush electrode0.50m19.7″

■

■

■

T99926623Spare wire brush electrode1.00m39″

■

■

■


   Diameter
Circular Wire Pipe Brush Probe    T99920071-1Internal circular wire pipe brush probe38mm1.5″

□

■

■

T99920071-2Internal circular wire pipe brush probe51mm2.0″

□

■

■

T99920071-3Internal circular wire pipe brush probe64mm2.5″

□

■

■

T99920071-4Internal circular wire pipe brush probe76mm3.0″

□

■

■

T99920071-5Internal circular wire pipe brush probe89mm3.5″

□

■

■

T99920071-6Internal circular wire pipe brush probe102mm4.0″

□

■

■

T99920071-7Internal circular wire pipe brush probe114mm4.5″

□

■

■

T99920071-8Internal circular wire pipe brush probe127mm5.0″

□

■

■

T99920071-9Internal circular wire pipe brush probe152mm6.0″

□

■

■

T99920071-10Internal circular wire pipe brush probe203mm8.0″

□

■

■

T99920071-11Internal circular wire pipe brush probe254mm10″

□

■

■

T99920071-12Internal circular wire pipe brush probe305mm12″

□

■

■

T99920071-13Internal circular wire pipe brush probe356mm14″

□

■

■

T99920071-14 Internal circular wire pipe brush probe406mm16″

□

■

■

T99920071-15Internal circular wire pipe brush probe508mm20″

□

■

■

T99920071-16 Internal circular wire pipe brush probe610mm24″

□

■

■

T9993766-Spare circular wire brush electrode38mm1.5″

■

■

■

T9993767-Spare circular wire brush electrode51mm2.0″

■

■

■

T9993768-Spare circular wire brush electrode64mm2.5″

■

■

■

T9993769-Spare circular wire brush electrode76mm3.0″

■

■

■

T9993770-Spare circular wire brush electrode89mm3.5″

■

■

■

T9993771-Spare circular wire brush electrode102mm4.0″

■

■

■

T9993772-Spare circular wire brush electrode114mm4.5″

■

■

■

T9993773-Spare circular wire brush electrode127mm5.0″

■

■

■

T9993774-Spare circular wire brush electrode152mm6.0″

■

■

■

T9993775-Spare circular wire brush electrode203mm8.0″

■

■

■

T9993776-Spare circular wire brush electrode254mm10″

■

■

■

T9993777-Spare circular wire brush electrode305mm12″

■

■

■

T9993778-

Spare circular wire brush electrode

356mm

14″

■

■

■

T9993779-

Spare circular wire brush electrode

406mm

16″

■

■

■

T9993780-

Spare circular wire brush electrode

508mm

20″

■

■

■

T9993781-

Spare circular wire brush electrode

610mm

24″

■

■

■

□ Older Elcometer 236 models may require adaptor piece T99922768

 Part NumberDescription  Compatible with Elcometer
     236266280
Wire Brush Probes, band brush, flat brush, internal and external pipe brush probes
‘C-type’ Wire BrushT99922752‘C-type’ wire brush holder† (order C-type brush from the list below)

□

■

■

T99922907‘C-type’ wire brush support handle*

□

■

■


  Outside Diameter (OD)
  DNNPS
T99922745-1External ‘C-type’ wire brush150 – 250mm6 – 9″

■

■

■

T99922745-2External ‘C-type’ wire brush250 – 350mm9 – 12″

■

■

■

T99922745-3External ‘C-type’ wire brush350 – 450mm12 – 16″

■

■

■

T99922745-4External ‘C-type’ wire brush450 – 550mm16 – 20″

■

■

■

T99922745-5External ‘C-type’ wire brush550 – 650mm20 – 24″

■

■

■

T99922745-6External ‘C-type’ wire brush650 – 750mm24 – 28″

■

■

■

T99922745-7External ‘C-type’ wire brush750 – 850mm28 – 32″

■

■

■

T99922745-8External ‘C-type’ wire brush850 – 950mm32 – 36″

■

■

■

T99922745-9External ‘C-type’ wire brush950 – 1050mm36 – 40″

■

■

■

T99922745-10External ‘C-type’ wire brush1050 – 1150mm40 – 44″

■

■

■



† Wire brush supplied separately

* Wire brush support handle ideal for two handed use or second person for large diameters


Conductive Rubber Probes
Conductive Rubber Probe   Width
T99920022-11Right angled rubber probe250mm9.8″

□

■

■

T99920022-12Right angled rubber probe500mm19.7″

□

■

■

T99920022-13Right angled rubber probe1000mm39″

□

■

■

T99920022-14Right angled rubber probe1400mm55″

□

■

■

 T99926731Spare rubber electrode250mm9.8″

■

■

■

 T99926732Spare rubber electrode500mm19.7″

■

■

■

 T99926733Spare rubber electrode1000mm39″

■

■

■

 T99926734Spare rubber electrode1400mm55″

■

■

■



□ Older Elcometer 236 models may require adaptor piece T99922768

















Rolling Springs Holders



T99920086

Phosphor bronze rolling spring holder

□

■

■



T99922746

Stainless steel rolling spring holder

□

■

■



Rolling Springs; Available in phosphor bronze or stainless steel

Phosphor Bronze Rolling SpringStainless Steel Rolling SpringNominal Pipe SizePipe Outside Diameter (OD)
DNNPSmillimeters (mm)inches (”)
Phosphor BronzeStainless Steel(mm)(inches)min ODmax ODmin ODmax OD
T99920438-15A
T99920438-15B		–
–		401.548541.92.1
54602.12.4
T99920438-20A
T99920438-20B

–
–

502.060662.42.6
66732.62.9
T99920438-25A
T99920438-25B		T99922744-25A
T99922744-25B		652.573802.93.1
80883.13.5
T99920438-30A
T99920438-30B		T99922744-30A
T99922744-30B		803.088953.53.7
951003.73.9
T99920438-35A
T99920438-35B		T99922744-35A
T99922744-35B		903.51001083.94.3
1081144.34.5
T99920438-40AT99922744-40A1004.01141254.54.9
T99920438-45A
T99920438-45B		T99922744-45A
T99922744-45B		1144.51251364.95.4
1361415.45.6
T99920438-50A
T99920438-50B		T99922744-50A
T99922744-50B		1255.01411555.66.1
1551686.16.6
T99920438-60A
T99920438-60B		T99922744-60A
T99922744-60B		1526.01681806.67.1
1801937.17.6
T99920438-70A
T99920438-70B		T99922744-70A
T99922744-70B		1787.01932137.68.4
2132198.48.6
T99920438-80AT99922744-80A2038.02192408.69.4
T99920438-90AT99922744-90A2299.02402649.410.4
T99920438-100AT99922744-100A25410.026429010.411.4
T99920438-110AT99922744-110A27911.029032011.412.6
T99920438-120AT99922744-120A30512.032035012.613.8
T99920438-140A
T99920438-140B		T99922744-140A
T99922744-140B		35614.035037513.814.8
37540014.815.7
T99920438-160A
T99920438-160B 		T99922744-160A
T99922744-160B 		40616.040043515.717.1
43545017.117.7
T99920438-180AT99922744-180A45718.045050017.719.7
T99920438-200AT99922744-200A50820.0500

550

19.721.7
T99920438-220AT99922744-220A55922.055060021.723.6
T99920438-240AT99922744-240A61024.060065023.625.6
T99920438-260AT99922744-260A66026.065070025.627.6
T99920438-280AT99922744-280A71128.070075027.629.5
T99920438-300AT99922744-300A76230.075081029.531.9
T99920438-320AT99922744-320A81332.081086031.933.9
T99920438-340AT99922744-340A86434.086091033.935.8
T99920438-360AT99922744-360A91436.091096035.837.8
T99920438-380AT99922744-380A95638.0960101037.839.8
T99920438-400AT99922744-400A101640.01010106039.841.7
T99920438-420AT99922744-420A106742.01060111041.743.7
T99920438-440AT99922744-440A111844.01110116043.745.7
T99920438-460AT99922744-460A116846.01160121045.747.6
T99920438-480AT99922744-480A121948.01210127047.650.0
T99920438-500AT99922744-500A127050.01270132050.052.0
T99920438-520AT99922744-520A132152.01320137052.053.9
T99920438-540AT99922744-540A137254.01370142553.956.1
Other sizes are available upon request. Please contact your nearest distributor for more information.
 Part NumberDescriptionOutside Diameter Compatible with Elcometer
     280
Grounding Mats
Grounding mats are ideal for testing on un-grounded pipes. The conductive rubber mat is wrapped around the coated pipe and connected to both the grounding pin (supplied separately) and the signal return lead.
   DNNPS
Grounding Mat

T28022637-1

Grounding Mat

up to 229mm

up to 9″

■

T28022637-2

Grounding Mat

up to 457mm

up to 18″

■

T28022637-3

Grounding Mat

up to 762mm

up to 30″

■

T28022637-4

Grounding Mat

up to 1067mm

up to 42″

■

Conductive Rubber Mat

T28022748

Grounding pin; 60cm (23.5″) long

■

T28022749

10m (32’) earth lead, clips each end

■

T28022750

10m (32’) earth lead, clip / Elcometer 280 connector

■

Download Datasheet
