Elcometer 500 Concrete Coating Thickness Gauge
Technical Specification | ||
| Part Number | Description | Certificate |
A500C-B | Elcometer 500 Coating Thickness Gauge Model B | ● |
A500C-T | Elcometer 500 Coating Thickness Gauge Model T | ● |
A500-KIT1 | Elcometer 500 Coatings on Concrete Inspection Kit | ● |
Operating Temperature | -10 to 50°C (14 to 122°F) | |
| Power Supply | 2 x AA batteries (rechargable batteries can be used) | |
| Battery Life | Alkaline: Approximately 15 hours Lithium: Approximately 28 hours | |
| Gauge weight | 161g (5.68oz) including batteries, without transducer | |
| Gauge Dimensions | 141 x 73 x 37mm (5.55 x 2.87 x 1.46”) without transducer | |
| Packing List | Elcometer 500 Coating Thickness Gauge Model B & T Elcometer 500 Coating Thickness Gauge, 4ml (0.14fl oz) Bottle of Probe Tip Oil, 120ml (4fl oz) Bottle of Ultrasonic Couplant, 2 x AA Batteries, Protective Case, Transit Case (Model T), Wrist Harness, 3 x Screen Protector, ElcoMaster® Software (Model T), USB Cable (Model T), Test Certificate Elcometer 500 Coatings on Concrete Inspection Kit Elcometer 500 Model T Coating Thickness Gauge, C1 & C2 coating thickness probes, C1 & C2 probe measurement foils: 1, 2, 3 & 8mm (40, 80, 120 & 310mils), Elcometer 456 Model B Ferrous Integral Gauge, Elcometer 456 calibration foils: 0.5 & 1.5mm (20 & 60mils), 2 x coating calibration moulds, 2 x Wrist Harness, 6 x Screen Protector, 120ml (4fl oz) bottle of ultrasonic couplant, 4ml (0.14fl oz) bottle of probe tip oil, transit case, ElcoMaster® software & USB cable | |
